M14 3 Wire Waterproof Connector

HuaYi-FaDa Technology, a leading domestic manufacturer of waterproof connectors, has launched the M14 3-Wire Waterproof Connector. Featuring a soldered wiring structure for enhanced sealing, it is compatible with 2/3/4/5/6/8-pin configurations, simultaneously meeting power and signal transmission requirements. Our M14 waterproof connectors offer a complete range of male and female connectors and panel mount options, simplifying equipment assembly and mass production processes for our customers. They are widely used in outdoor lighting, industrial automation, new energy, and 5G communications.

We are committed to providing stable quality and on-time delivery services to our global customers. Choosing the M14 3-Wire Waterproof Connector means choosing a long-term, stable connection solution.

Parameter

Product Features

1. Sealing and Waterproofing

Utilizes dual protection with silicone seals and welded terminations, achieving an IP68 waterproof rating, ensuring stable operation underwater and in humid environments.

The male-female connector structure with threaded locking reduces the risk of loosening and water ingress.

2. Stable Electrical Performance

Gold-plated copper alloy contacts reduce contact resistance and improve signal and power transmission stability.

Insulation and withstand voltage meet industrial equipment safety standards, reducing the risk of short circuits and breakdowns.

Supports mixed power and signal transmission (e.g., 2+4 pins), adaptable to various device interfaces.

3. Mechanical and Environmental Adaptability

The housing is made of high-strength engineering plastic, offering impact resistance, deformation resistance, and aging resistance.

Wide operating temperature range, suitable for long-term use in extreme cold and high temperature outdoor and industrial environments.

UL94-V0 flame retardant, meeting equipment safety specifications.

4. Installation and Adaptation

Supports wire-to-wire and wire-to-panel mounting, with a complete set of male and female connectors.

Multiple core counts are available, covering the wiring needs of common sensing, lighting, and control equipment.

Welded wiring facilitates on-site construction and mass production.

Product Details

Connection:

Product Qualification of M14 3 Wire Waterproof Connector

This M14 3 Wire Waterproof Connector has passed CE, RoHS certificate. It is with IP68 waterproof level.

Application Scenarios

The M14 3 Wire Waterproof Connector is suitable for connecting devices requiring waterproofing, dustproofing, and stability:

Outdoor Lighting: LED streetlights, wall washers, landscape lights, floodlights

Industrial Automation: Sensors, actuators, control modules

New Energy: Photovoltaic modules, energy storage equipment, charging pile interfaces

5G Communication: Base station peripherals, monitoring equipment, outdoor cabinets

Rail Transit and Environmental Vehicles: Onboard electrical components, external signal connections

Machinery Equipment: Machine tools, outdoor instruments, engineering machinery wiring

Technical Advantages

Mature Waterproof Structure

Multi-layer sealing design, passed long-term immersion testing, ensures no leakage in outdoor and humid environments.

Gold-plated Contact Process

Oxidation and corrosion resistant, maintaining low contact resistance and extending service life.

Precision Mold and Injection Molding

Good dimensional consistency, smooth male and female fit, moderate insertion and extraction force, facilitating mass assembly.

Full-Process Quality Control

Standardized testing is performed from raw materials, injection molding, hardware to finished product assembly, reducing defect rates.

Rapid customization capability: Supports OEM/ODM adjustments for cable length, core count, appearance, and cable exit method to adapt to customer equipment structures.
